Televes 550104 Power Supply Unit, UL Listed, Built-in 2-Ways Splitter, 12V 220mA, F-Connector, Antenna Power Inserter

Televes 550104 Power Supply Unit, UL Listed, Built-In 2-ways Splitter, 12V 220mA, F-Connector, Antenna Power Inserter Domestic 12 V power supply designed to feed antennas and mast amplifiers through coax while allowing TV signal passage. UL listed for indoor use and fitted with two F-connector outputs for easy distribution. KeyFeatures: - UL listed for indoor use - 12 Vdc output - 220 mA maximum output current - Two F-connector outputs - Frequency range 5-862 MHz - Low insertion loss single output 1.5 dB - Insertion loss two outputs 4 dB - Input voltage 108-132 Vac - Max power consumption 3.6 W - Wall-mountable compact design - Operating temperature 14-113 F Specifications: - Output voltage: 12 Vdc - Max output current: 220 mA - Number of outputs: 2 - Frequency range: 5-862 MHz - Insertion loss (1 output): 1.5 dB - Insertion loss (2 outputs): 4 dB - Input voltage: 108-132 Vac - Max power consumption: 3.6 W - Operating temperature: 14 to 113 F - Protection index: IP20 - Net weight: 292 g (0.64 lb) - Dimensions (W x H x D): 146 x 54 x 35 mm (5.75 x 2.13 x 1.38 in)
