SEQURE 200A Brushless ESC 5-14S Lipo Electric Speed Controller with 12V 15A BEC and 5V Fan for Drones Helicopters RC Cars Surfboards - AM32
SEQURE 200A Brushless ESC 5-14S Lipo Electric Speed Controller with 12V 15A BEC and 5V Fan for Drones Helicopters RC Cars Surfboards - AM32
Description
SEQURE 14200 Pro ESC 200A Brushless Electronic Speed Controller Specification: Model: SQESC 14200 Pro Processor: STM32G071 Input voltage: DC 18V-59V(5-14S Lipo) Continuous Current: 200A Peak Current: 350A Support firmware: AM32 Signal Protocols: Dshot (All), PWM, Oneshot, Multishot, etc. BEC：6V/7.4V/8.4V/12V, 15A Continuous current 35A peak current. Fan: 5V 0.5A continuous current Functions: Forward, Reverse, Brake Program parameter adjustments: Yes Steering Setting of the Motor: Yes RPM Specialized Signal: Yes Accelerator calibration: Yes Timing Angle Setting: Yes Current Detection: Yes Telemetry signal: Yes RGB LED Light: Yes Fan: Yes Power Cable: 8AWG silicone wire 160mm Motor Cable: 10AWG silicone wire 160mm Features: Equipped with high-power MOSFET, and combined with CNC metal radiator, this ESC dissipates heat effectively under high current load and works stably & continuously. The pads for power supply and motor are designed with high and thick copper, large area immersion gold, and via hole process, allowing for easy handling of high current. High quality twisted pairs cable effectively reduces the interference during signal transmission, ensuring stable and precise transmission. Reserved position for tie straps, convenient to fix devices in various scenarios, firm and not easily loose. Visual programming parameter adjustment tool supports motor timing, throttle calibration, current detection, motor steering, telemetry signal, and other settings. Onboard RGB LED color light settings, multiple LED colors can be customized. Suitable for multi-axis UAV, fixed-wing drones, crop protection aircraft, helicopters, multi rotor drones, climbing cars, off-road model vehicles, model ships, surfboards, water sports products, etc
Item Details
Seller
Nellis Auction
Pickup Location
4031 Market Center Dr Suite 303
North Las Vegas, NV, 89030
Quality
Estimated Retail Price
$149.03
Buyers Premium
15%
Inventory Number
1075184357
Found in
Additional Details from the Manufacturer
This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing
brand
SEQUREcolor
14200 Pro(am32)size
AM32More features
- Firmware: AM32, Processor: STM32G071, Working voltage: DC 18V-59V(5-14S Lipo), Constant current: 200A, Peak current: 350A
- 14200 Pro is equipped with a dip switch system to adjust the voltage of BEC from 6V,7.4V,8.4V,12V. The continuous current of BEC is 15A, while peak current is 35A.
- The ESC automatically detects the throttle signal when it is powered on, supports all Dshot signals, and also supports signal protocols such as PWM, Oneshot and Multishot.
- Supports RPM specialized signal, throttle calibration, current detection, motor steering, telemetry signal, and other settings.
- Suitable for drones, quadcopters, helicopters, rc crawler cars, model ships, surfboards, water sports products, etc.
