Pro Chaser DC-DC Golf Carts RVs 48V 36V Volt Voltage to 12V Step Down Voltage Reducer Regulator for Headlights Taillights Solar Panels Radios (30A 360W)

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 360 W DC–DC Voltage Regulator – Steps 36 V (six 6 V batteries) or 48 V (six 8 V batteries) golf-cart/RV battery packs down to a stable 12 V/30 A output for headlights, taillights, radios, solar panels, and more.
• Color-Coded Harness & Manual – Includes matched connectors and butt-connectors plus a full-color manual with single-line wiring: thin black → battery (–), thick red → battery (+), thick black → accessory (–), yellow → accessory (+), thin red → key-switch “switched” terminal (probe with multimeter).
• Safety & Installation Tips – Torque all terminals to 4–6 N·m to prevent arcing; secure converter, harness, and wires under vehicle to avoid chafing; install in 0 °C–50 °C, ≤ 85 % RH, with free airflow around the aluminum-cast shell’s vents.
• Built-In Protection & Reliability Testing – Never exceed 360 W continuous load (peak surges ≤ 400 W); overload protector trips on over-current (remove load and wait 60 s before retry); each unit passes automated optical inspection, 1 h full-load burn-in, and surge/overload simulation.
• Refer to the final image in the photo gallery for detailed, step-by-step wiring instructions.
