Model 7050 Standard Hydraulic Actuator for CMC Power-Lift and PT-130 / PT-35, T-H Marine Hydro-Jacker, and ATLAS Tilt & Trim Systems, Self-Contained Marine Hydraulic Power Unit, 5" Stroke

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• Wide Compatibility - Fits CMC Power-Lift hydraulic jack plates (61001, 61002, 65001, 65002, 65501, 65502), T-H Marine Hydro-Jacker plates (HYJ-6C-DP, HYJ-10C-DP), CMC Power Tilt & Trim units (13001, 13002), and ATLAS Tilt & Trim units (THT-130C-DP)
• All-in-One Hydraulic Design - Integrates electric motor, hydraulic pump, fluid reservoir, and cylinder in a single unit—no external hoses or additional components required
• Marine-Grade Construction - Made from 100% non-ferrous materials with a no-leak seal and wiper system to keep dirt and water out, fully submersible for reliable operation in freshwater or saltwater environments
• Powerful Hydraulic Performance - Stroke length of 5", thrust rating up to 5,000 lbs. extend and 3,750 lbs. retract, providing smooth lift, trim, and tilt movement
• Easy Replacement - Direct-fit replacement for standard Power-Lift, Hydro-Jacker, and Tilt & Trim systems with one-piece motor/hydraulic actuator assemblies. Not for high-speed jack plate models
• Restores Lift and Trim Function - Ideal solution when your jack plate or tilt & trim unit will not raise or lower due to actuator failure or internal leakage
