Description

Features STM32H743 MCU running at 480 MHz High-Precision / low-noise ICM-42688-P IMU CAN Bus Support Dual Camera Inputs switch 3 On-board BEC output 5V, 6V/8V and 9V/12V 9V/12V ON/OFF Pit Switch On-board voltage & current sensor Integrated BMP280 barometer Plug-and-play GPS, CAN, I2C ports Small & low-profile design fits into compact frames Supports INAV (6.1.1 & later), Ardupilot (4.4 & later) Package Includes 1x Kakute H743-Wing Flight Controller 1x Power Board 1x Top Board 1x USB-EXT Board 1x Electrolytic capacitor: 220uF 62v 2x XT60 60mm Power Cable 3x 2.54 DuPont Pin 2x 15cm JST-GH 4Pin Cable (For CAN & I2C Port 1x 15cm JST-SH 6Pin Cable (For USB-EXT Board)

Item Details

Seller

Nellis Auction

Pickup Location

6520 Westwind Rd, Ste 100

Las Vegas, NV, 89118

Quality

New

Functional

No Damage

No Assembly Needed

In Package

No Missing Parts

Estimated Retail Price

$163.70

Buyers Premium

15%

Inventory Number

1093017972

Found in

Toys & Games

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

brand

SoloGood

color

Black

dimensions

Package: 0.01 lb

weight

0.01 lbs

More features

The Holybro Kakute H743 Wing is a full featured flight controller with layout specifically for fixed wing & VTOL applications. It has the STM32 H743 Processor running at 480 MHz and CAN Bus support, along with dual camera support & switch, ON/OFF Pit Switch, 5V, 6V/8V, 9V/12 BEC, and plug-and-play GPS, CAN, I2C ports.
MCU: STM32H743, 480 MHz, 1MB RAM, 2MB Flash.IMU: ICM-42688P (SPI3).Baro: BMP280 (I2C4).OSD: AT7456E (SPI2).Blackbox: MicroSD card slot on SDMMC2MCU: STM32H743, 480 MHz, 1MB RAM, 2MB Flash.IMU: ICM-42688P (SPI3).Baro: BMP280 (I2C4).OSD: AT7456E (SPI2).Blackbox: MicroSD card slot on SDMMC2MCU: STM32H743, 480 MHz, 1MB RAM, 2MB Flash.IMU: ICM-42688P (SPI3).Baro: BMP280 (I2C4).OSD: AT7456E (SPI2).Blackbox: MicroSD card slot on SDMMC2
7x Uarts (1,2,3,5,6,7,8) with built-in inversion.14x PWM outputs, 1x CAN, 5x ADC (Bat1/Curr1, Bat2/Curr2 and RSSI).3x I2C (I2C1 and I2C2 for external devices, I2C4 for onboard sensors).3x LEDs for FC STATUS (Blue, Red) and 3.3V indicator (Green)
USB/DFU Key Extender with USB Type-C.Dual Camera Inputs switch.5V/9V(12V) for Camera/VTX power switch.High-precision Current Sense (90A continuous, 220A peak).Battery Voltage Sensor: 5K:25.5K (Scale 1800 in INAV, BATT_VOLT_MULT 18.18 in ArduPilot) Static power 160mA@5V
Ardupilot Target: KAKUTEH7-Wing(Ardupilot 4.4 or newer) INAV Target: KAKUTEH7Wing (INAV 6.1.1 or newer)
