ANNIMOS 35KG High Torque Servo 8.4V Coreless RC Steering Servo Motors Stainless Steel Gear Low Profile Waterproof for 1/8 1/10 1/12 Scale Cars DIY Robotic - 180 Degree
ANNIMOS 35KG High Torque Servo 8.4V Coreless RC Steering Servo Motors Stainless Steel Gear Low Profile Waterproof for 1/8 1/10 1/12 Scale Cars DIY Robotic - 180 Degree
Description
Electrical Specification： Operating voltage range: 5-8.4 Volts Operating speed at no load ( 5V ): 0.18 sec/60° Operating speed at no load ( 7.4V ): 0.13 sec/60° Operating speed at no load ( 8.4V ): 0.11 sec/60° Stall torque at locked ( 5V ): 35kg.cm(486oz-in) Stall torque at locked ( 7.4V ): 46kg.cm(638.8oz-in) Stall torque at locked ( 8.4V ): 51kg.cm(708.2oz-in) Stall current at locked ( 5V ): 3.5A Stall current at locked ( 7.4V ): 5.2A Stall current at locked ( 8.4V ): 5.8A Idle current at stopped (5/7.4/8.4V): 5mA Control Specification: Control System: PWM (Pulse width modification) Pulse width range: 500-2500μsec Neutral position: 1500μsec Running degree: 180° (when 500-2500μsec) Dead band width: 2μsec Operating frequency: 50-330Hz Rotating direction: Counterclockwise (When 1500-2500μsec) Product Specification: Suitable for: for 1/8 1/10 1/12 Scale RC Cars, Trucks Motor Type：Coreless Motor Gear Type: Stainless Steel Spline:25 Tooth Gear ratio: 342 Bearing：Double Bearing Waterproof Performance：IP67 Connector Wire: 17.7in (450mm) Size: 1.57*0.79*1.59inch（40 * 20 * 38.5mm） Weight: 2.11oz (60g) CE /RoHs: Yes Apply Environmental Conditon: Storage Temperature Range:-30°C~80°C Operating Temperature Range:-25°C~70°C Packing List: 1 x DS3245SG 45kg Servo （180° ） 1 x 25T Adjustable Metal Servo Arm 1 x Accessories Set (As Shown on The Picture)
Item Details
Seller
Nellis Auction
Pickup Location
7440 Dean Martin Dr Suite 204
Las Vegas, NV, 89139
Quality
Estimated Retail Price
$31.16
Buyers Premium
15%
Inventory Number
1060284133
Found in
Additional Details from the Manufacturer
This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing
brand
ANNIMOSsize
45KG-180°More features
- 【Widely Used】: DS3245SG 45kg Full Metal Gear Standard Servo Suitable for RC Off-road Vehicle, Crawler, Mechanical Arms, Robots, Remote Control Boat & Giant Scale Aircraft etc.
- 【Great Heavy-Duty Servo】: Amazing Torque & Fast Performance, Perfect for Heavy-duty RC Vehicle, Maximum Torque Can Up to 51kg.cm(708.2oz-in),Speed sec/60°:0.11@8.4v
- 【Reliable Quality】: Equipped with High-precision Steel Gear and Potentiometers , High-resolution Digital Chip, Waterproof Rubber Seals Screws, Made of First-grade Material and CNC Aluminum Middle Shell Ensure Stable Performance and Long Working Life.
- 【Best Upgrade for your RC Rigs】: Durable, Responsive, Strong Anti-interference Ability, Low Noise, Fast Heat Dissipation.Precision Control, Angle Range from 0 to 270 Degrees. Can be Rotated within 360 Degrees when Power Off, Perfect for Robot Joint Activities. Up to 45mm Long Wire. Free 25T Servo Horn and Accessories
- 【Satisfied Customer Service】: We Are Specialized in Developing and Manufacturing Robot & RC Servo, We Offer Value Price for Bulk Order. If Any Problem with Your Servo or Anything We Can Help, Please Do Not Hesitate to Contact with Us, We Will Try Our Best to Solve it Efficiently.
