3600w Solar Inverter 24VDC to 110V/120VAC Pure Sine Wave Inverter

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• All-in-one Design: 3600W solar inverter converts 24V DC to 110V/120V AC, integrating a 120A MPPT charge controller. Inverter is compatible with 24V Lead-Acid (Seal, AGM, Gel, Flooded) and lithium batteries. The solar charge module uses optimized MPPT tracking technology, achieving an impressive 98% efficiency, ensuring rapid and stable charging
• Intuitive Monitoring System: Inverter LCD display along with 3 LED indicators dynamically shows system data and operating status. You can configure battery charging current, ac/solar charger priority and load supply priority via inverter effortlessly monitor the system data and operation status
• Technical Specifications: Hybrid inverter with Max. PV input power of 4200W, rated output power 3600W and peak/surge power 7200W (for motor startup), PV input voltage range 60V‑500VDC, Max. PV input current 16A, Max. AC input current 40A, nominal input frequency 60Hz, solar charge current 120A and built‑in AC battery charger 100A, handling high‑power demands with ease. Suggest PV cable size: ≥10AWG; AC input cable size: ≥6AWG (please refer to the manual for exact sizing under full load)
• Diverse Charging & Output Modes: Hybrid solar inverter has 4 charging modes to choose from solar, mains first, solar first, and mains & solar hybrid charging. 3 output modes: solar first, mains first, and sbu priority, that's ensures an uninterrupted power supply. Hybrid inverter can work with mains voltage or generator power, auto-restarting when ac recovers
• Wide Application: 3600W hybrid solar inverter ideal for rv trips, boating, family life and emergencies. Power up all sorts of home and office appliances, like ovens, rice cookers, lights, tvs and fans. Whether it's solar or grid power, you'll always get stable electricity, plus save on high energy costs
